雙節距滾子鏈（C型）是以JIS和ANSI規格為基準的標準滾子鏈的2倍節距的鏈條。,主要用于低速傳動和搬運,有標準直徑S型滾子和,、大徑R型滾子 雙節距附件滾子鏈?zhǔn)窃陔p節距滾子鏈上附加附件的鏈條,主要用于搬送
|
鏈號
|
鏈號
|
節距
|
滾子直徑 |
內節內寬 |
銷軸直徑 |
銷軸長度 |
內鏈板高度 |
鏈板厚度 |
極限拉伸載荷 |
平均拉伸載荷 |
每米長重 |
| P |
d1 mASSx |
BSS1 min |
d2 mASSx |
L mASSx |
Lc mASSx |
h2 mASSx |
t/T mASSx |
Q min |
Qo |
q |
| mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
kN |
kN |
kg/m |
| C208ASS |
C2040SS |
25.40 |
7.95 |
7.85 |
3.96 |
16.6 |
17.8 |
12.0 |
1.50 |
8.46 |
10.02 |
0.42 |
| C208BSS |
|
25.40 |
8.51 |
7.75 |
4.45 |
16.7 |
18.2 |
11.8 |
1.60 |
10.80 |
11.64 |
0.45 |
| C210ASS |
C2050SS |
31.75 |
10.16 |
9.40 |
5.08 |
20.7 |
22.2 |
15.0 |
2.03 |
13.32 |
16.92 |
0.73 |
| C210BSS |
|
31.75 |
10.16 |
9.65 |
5.08 |
19.5 |
20.9 |
14.7 |
1.70 |
13.44 |
16.50 |
0.65 |
| C212ASS |
C2060SS |
38.10 |
11.91 |
12.57 |
5.94 |
25.9 |
27.7 |
18.0 |
2.42 |
19.08 |
22.08 |
1.02 |
| C212BSS |
|
38.10 |
12.07 |
11.68 |
5.72 |
22.5 |
25.2 |
16.0 |
1.85 |
17.40 |
19.32 |
0.76 |
| C216ASS |
C2080SS |
50.80 |
15.88 |
15.75 |
7.92 |
32.7 |
36.5 |
24.0 |
3.25 |
34.02 |
39.42 |
1.70 |
| C216AHSS |
|
50.80 |
15.88 |
15.75 |
7.92 |
36.2 |
39.4 |
24.0 |
4.00 |
34.02 |
42.00 |
2.17 |
| C216BSS |
|
50.80 |
15.88 |
17.02 |
8.28 |
36.1 |
39.1 |
21.0 |
4.15/3.1 |
36.00 |
43.68 |
1.75 |
| C220ASS |
C2100SS |
63.50 |
19.05 |
18.90 |
9.53 |
40.4 |
44.7 |
30.0 |
4.00 |
53.10 |
61.56 |
2.55 |
| C220BSS |
|
63.50 |
19.50 |
19.56 |
10.19 |
41.3 |
45.0 |
26.4 |
4.5/3.5 |
57.00 |
64.02 |
2.62 |
| C224ASS |
C2120SS |
76.20 |
22.23 |
25.22 |
11.10 |
50.3 |
54.3 |
35.7 |
4.80 |
76.20 |
88.38 |
4.06 |
| C224BSS |
|
76.20 |
25.40 |
25.40 |
14.63 |
53.4 |
57.8 |
33.2 |
6.0/4.8 |
96.00 |
106.80 |
4.70 |
| C228BSS |
|
88.90 |
27.94 |
30.99 |
15.90 |
65.1 |
69.5 |
36.7 |
7.5/6.0 |
120.00 |
133.20 |
6.23 |
| C232BSS |
|
101.60 |
29.21 |
30.99 |
17.81 |
|
| |
